2027 PITTS LB55-22DC TPILB5522DCFTL Web

2026 PITTS LB55-22DC HYDRAULIC DETACHABLE GOOSENECK Pony Motor option available*, 4th Axle Option Available ***Available in 51 Ton & 35 Ton Capacity*** *FET Additional* Delivery charges may apply SPECS: - Capacity: 55 tons in 12a length (GAWR and tire ratings determine legal payloads) - Estimates Tare Weight (STANDARD PACKAGE): 20,100 lbs A+- 3% - Overall: 8a 6a width x 52a8a length - Clear deck length: 25a, (flat deck design) - Deck height under full load: 22a (ground clearance 6a) - 50a nominal loaded 5th wheel height (4 ride height positions) - Rear bogie height: 41a GOOSENECK DESIGN - Hydraulic, detachable with 9a cylinders. non-ground bearing, set up for wet line - Adjustable ride height features 4-position mechanical lock for separate deck and fifth wheel height control - Air locking pin - 102a swing radius DECK DESIGN - Main longitudinal members fabricated with 100 KSI yield steel flanges with 50 KSI yield webs - Level deck design - 10...
