2027 XL SPECIALIZED XL80MDE TXLMFGEXTJAX Web

XL 80 Mechanical Detachable Extendable **FET not Included** Delivery charges may apply Locations In FL & GA OVERALL LENGTH 48' OVERALL WIDTH 102" CAPACITY 80,000 LB DISTRIBUTED; 60,000 LB IN 10' CLOSED GOOSENECK LENGTH 10' FULL-WIDTH KINGPIN SETTING 16" SWING CLEARANCE 84" 5TH WHEEL HEIGHT 49" DECKING 1 1/8" APITONG DECKING, FLUSH D-RINGS ( 2 ) BENT D-RINGS PER SIDE ( 1 ) PAN STYLE D-RING IN EACH CORNER MUD FLAPS ALUMINUM MUD FLAPS TOOLBOX TOOLBOX IN BASE WITH LOCKABLE ALUMINUM LID, CHAIN RACK AND LIGHT FLIP NECK PREP FOR 36" FLIP NECK MAIN DECK LENGTH 29' / OPENING TO 50' 4" - 30" STATIONARY DECK LOADED DECK HEIGHT 20" W/ 6" GROUND CLEARANCE DECKING 1 1/8" APITONG DECKING, FLUSH, CENTER COVERED CROSSMEMBER 4" JR. I-BEAM AND KNEE BRACES ON 12" ALTERNATING CENTERS BEAMS ( 4 ) FAB I-BEAMS D-RINGS ( 8 ) BENT D-RINGS PER SIDE CHAIN DROPS 24" CENTERS - OUTSIDE BEAMS OUTRIGGERS REMOVABLE SWING OUT OUTRIGGERS ON 24" CENTERS RAMP TAPERS TO 4" REAR DECK LENGTH 9' LOADED DECK HEIGHT 40" AXLES ( 2 ) 25,000 LBS NOMINAL (5/8" WALL) SUSPENSION HENDRICKSON / 25,000 CAPACITY / AIR RIDE AXLE SPACING 54" ABS 4S2M WITH SPRING BRAKES ON ( 2 ) AXLES TIRES 255 / 70R / 22.5 ( H ) WHEELS 8.25 X 22.5 10-HOLE PILOT MOUNT POLISHED ALUMINUM OUTSIDE, STEEL INSIDE DISC BRAKES 16 1/2'' X 7" DRUMS OUTBOARD ELECTRICAL 12V SEALED GROTE SYSTEM WITH ( 3 ) TAIL LIGHT ALUMINUM PACKAGE 4" AMBER STROBE TO BE USED AS 3RD TAIL LIGHT DECKING 1 1/8" APITONG DECKING, FLUSH, COVERED WHEELS D-RINGS ( 1 ) PAN STYLE D-RING IN EACH CORNER D-RINGS ( 2 ) BENT D-RINGS IN TAIL CHANNEL PAINT BLACK ADDITIONAL DOUBLE DONUT FRONT CONNECTOR PLATE ( 2 ) PAIR OF FLAG HOLDERS PREP FOR FLIP AXLE...
