2027 XL SPECIALIZED XL60HDGSM TXLMFG60HDGSMMAC Web

XL 60 HDGSM **FET not Included** OVERALL LENGTH 53' OVERALL WIDTH 102" CAPACITY 60,000 LB DISTRIBUTED; 60,000 LB IN 16' WEIGHT +/- 3% 0,000 LB 0 GOOSENECK LENGTH 11' LOW PROFILE SCRAPER NECK DECKING FULL WIDTH STYLE WITH 1 1/8" APITONG DECKING FLUSH 2 BENT D-RINGS PER SIDE KINGPIN SETTING 16" SWING CLEARANCE 86" 5TH WHEEL HEIGHT 49" W/ 5 VARIABLE RIDE HEIGHT POSITIONS HYDRAULICS 13 HP HONDA SCU, DUAL HYDRAULICS, W/ STEEL COVER MAIN DECK ( 3 ) BEAM DESIGN LENGTH 33' WITH 32' 6"' OF CLEAR DECK LOADED DECK HEIGHT 12" W 4" GROUND CLEARANCE DECKING STEEL DECKING BETWEEN MAIN BEAMS WITH DURABAK 1 1/8" APITONG DECKING, FLUSH BETWEEN MAIN BEAMS AND OUTER BEAMS CROSSMEMBER 4" JR. I-BEAM ON 18" CENTERS MID-HEADER IN MAIN DECK BEAMS ( 3 ) 8" FAB BEAMS D-RINGS ( 12 ) BENT D-RINGS PER SIDE OUTRIGGERS NONE RAMPS TAPERS TO 4" CHAIN DROPS 18" O/C - OUTSIDE BEAMS REAR DECK LENGTH 9' LOADED DECK HEIGHT 40" AXLES ( 2 ) 25,000 LBS. NOMINAL (5/8" WALL) SUSPENSION HENDRICKSON / 25,000 CAPACITY / AIR RIDE AXLE SPACING 54" ABS 4S2M WITH SPRING BRAKES ON ( 2 ) AXLES TIRES 255 / 70R / 22.5 ( H ) WHEELS 8.25 X 22.5 10-HOLE PILOT MOUNT POLISHED ALUMINUM OUTSIDE, STEEL INSIDE DISC BRAKES 16 1/2'' X 7" DRUMS OUTBOARD ELECTRICAL 12V SEALED GROTE SYSTEM WITH ( 3 ) TAIL LIGHT ALUMINUM PACKAGE 4" AMBER STROBE TO BE USED AS 3RD TAIL LIGHT DECKING 1 1/8" APITONG DECKING, FLUSH D-RINGS ( 1 ) PAN STYLE D-RINGS IN EACH CORNER ( 2 ) BENT D-RINGS IN TAIL CHANNEL PAINT BLACK ADDITIONAL MANUAL RIDE HEIGHT CONTROL ( 2 ) PAIR OF FLAG HOLDERS 2' X 2' CUT OUT IN REAR TRANSITION LIQUID FILLED AIR GAUGE PREP FOR FLIP AXLE AND RAISE AND LOWER VALVE Delivery charges may apply Locations In FL & GA - We finance All Equipment! Even if you didn't buy from us!...
